BD-04AFMM-LR7A10
ActiveMcGill Microwave Systems
CERES, STANDARD SIZE, PLASTIC, 5A, 04 PINS, FEMALE CONNECTOR, MALE CONTACT, RIGHT ANGLE, 2 POINTS LOCK, OVERMOLDED, LENGTH 10000
BD-04AFMM-LR7A10
ActiveMcGill Microwave Systems
CERES, STANDARD SIZE, PLASTIC, 5A, 04 PINS, FEMALE CONNECTOR, MALE CONTACT, RIGHT ANGLE, 2 POINTS LOCK, OVERMOLDED, LENGTH 10000
Description
General part information
BD-04AFMM-LR7A10
Circular Cable Assembly Shielded 32.8' (10.00m)
Technical Specifications
Parameters and characteristics for this part
| Specification | BD-04AFMM-LR7A10 |
|---|---|
| 1st Connector Gender | Male Pins |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Connector Number of Positions | 4 positions |
| 1st Connector Number of Positions Loaded | All |
| 1st Connector Orientation | Keyed |
| 1st Connector Shell Size - Insert | B |
| 1st Connector Type | Right Angle, Receptacle |
| 2nd Connector Type | Wire Leads |
| Assembly Configuration | Standard |
| Cable Material | Polyvinyl Chloride (PVC) |
| Cable Type | Round |
| Color | Black |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Length | 32.8 ft |
| Shielding | Shielded |
| Usage | Industrial Environments |
