ZX47-40LN-S+
ActiveMini-Circuits
POWER DETECTOR / SMA / ROHS
ZX47-40LN-S+
ActiveMini-Circuits
POWER DETECTOR / SMA / ROHS
Description
General part information
ZX47-40LN-S+
RF Detector IC General Purpose 10MHz ~ 8GHz -40dBm ~ 20dBm Module, SMA Connectors
Technical Specifications
Parameters and characteristics for this part
| Specification | ZX47-40LN-S+ |
|---|---|
| Current - Supply | 100 mA |
| Frequency (Max) | 8 GHz |
| Frequency (Min) | 10 MHz |
| Input Level (Max) | 20 dBm |
| Input Level (Min) | -40 dBm |
| Mounting Type | Chassis Mount |
| Package / Case | Module, SMA Connectors |
| RF Type | General Purpose |
| Voltage - Supply (Maximum) | 5.5 V |
| Voltage - Supply (Minimum) | 4.5 V |
