PD30ETBR35BPM5IO
ActiveCarlo Gavazzi Inc.
PHOTO BGS RD 350MM SS IO-LINK, PLG
PD30ETBR35BPM5IO
ActiveCarlo Gavazzi Inc.
PHOTO BGS RD 350MM SS IO-LINK, PLG
Description
General part information
PD30ETBR35BPM5IO
Background Suppression Optical Sensor 13.780" (350mm) Push-Pull, NPN/PNP
Technical Specifications
Parameters and characteristics for this part
| Specification | PD30ETBR35BPM5IO |
|---|---|
| Adjustment Type | Adjustable, Potentiometer |
| Connection Method | M8, Connector |
| Ingress Protection | IP68, IP67, IP69K |
| Light Source | Red |
| Light Source Wavelength (Red) | 620 nm |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -25 °C |
| Output Configuration | PNP, NPN, Push-Pull |
| Response Time | 1 ms |
| Sensing Distance | 13.78 " |
| Sensing Method | Background Suppression |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
