Specification	612

Air Flow	24 CFM
Bearing Type	Ball
Fan Type	Tubeaxial
Material - Blade	Polyamide, PA, Nylon
Material - Frame	Fiberglass Reinforced, Polybutylene Terephthalate (PBT)
Noise	40 dB
Power (Watts)	2.5 W
Size / Dimension Height	60 mm
Size / Dimension Length	60 mm
Size / Dimension Shape	Square
Termination	2 Wire Leads
Termination Leads Count	2 leads
Termination Type	Wire Leads
Voltage - Rated	12 VAC
Voltage Range (Max)	15 V
Voltage Range (Min)	6 VDC
Weight	0.19 lb
Width	1 in
