1010653
ActiveIntegrated Power Designs
DC/DC CONVERTER 5V +/-15V 110W
1010653
ActiveIntegrated Power Designs
DC/DC CONVERTER 5V +/-15V 110W
Description
General part information
1010653
Open Frame DC DC Converter 3 Output 5V 15V -15V 10A, 2A, 2A 72V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | 1010653 |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | cURus, UKCA, TUV, CE |
| Current - Output (Max) Options | 10A, 2A |
| Efficiency | 82 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 3 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 110 W |
| Size / Dimension Height | 1.32 in |
| Size / Dimension Length | 5 in |
| Size / Dimension Width | 3 in |
| Standard Number | 60601-1, 62368-1 |
| Type | Open Frame |
| Voltage - Input (Max) | 72 V |
| Voltage - Input (Min) | 36 V |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | 15 V |
| Voltage - Output 4 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
