493176-2
ActiveTE Connectivity AMP Connectors
CONN RING ANGLED 4-5AWG CRIMP
493176-2
ActiveTE Connectivity AMP Connectors
CONN RING ANGLED 4-5AWG CRIMP
Description
General part information
493176-2
Closed Ring Tongue Terminal, 5 – 4 AWG, 3/8 Stud, 9.6 mm [.378 in] Stud Diameter, Open Barrel, Right Angle, Tin Plating, Uninsulated
Technical Specifications
Parameters and characteristics for this part
| Specification | 493176-2 |
|---|---|
| Insulation | Non-Insulated |
| Mounting Type | Right Angle, Free Hanging (In-Line) |
| Terminal Type | Circular |
| Termination | Crimp |
| Thickness | 0.079 in |
| Width - Outer Edges | 0.705 in |
| Wire Gauge (AWG) (Max) | 5 AWG |
| Wire Gauge (AWG) (Min) | 4 AWG |
