FB201209T-101Y-S
ActiveCal-Chip Electronics, Inc.
FERRITE BEAD 100 OHM 0805 1LN
FB201209T-101Y-S
ActiveCal-Chip Electronics, Inc.
FERRITE BEAD 100 OHM 0805 1LN
Description
General part information
FB201209T-101Y-S
100 Ohms @ 100 MHz 1 Signal Line Ferrite Bead 0805 (2012 Metric) 300mA 200mOhm
Technical Specifications
Parameters and characteristics for this part
| Specification | FB201209T-101Y-S |
|---|---|
| Current Rating (Max) | 300 mA |
| DC Resistance (DCR) (Max) | 200 mOhm |
| Filter Type | Signal Line |
| Height (Max) | 0.043 in |
| Impedance | 100 Ohms |
| Mounting Type | Surface Mount |
| Number of Lines | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0805 (2012 Metric) |
| Size / Dimension Length | 0.079 in |
| Size / Dimension Width | 0.049 in |
