Specification	0ALEB9200-PD

Applications	Electrical, Industrial
Breaking Capacity	20 kA
Current Rating	20 A
DC Cold Resistance	0.0000051 Ohms
Fuse Type	Cartridge
Melting I²t	435
Mounting Type	Bolt Mount
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Package / Case	Blade Terminal (Bolt), Cylindrical
Size / Dimension Diameter	0.409 in
Size / Dimension Length	1.496 in
Voltage Rating - DC	500 V
