Description
General part information
30POEX_4812-A
Isolated PoE (Power over Ethernet) Module DC DC Converter 1 Output 12V 2.5A 36V - 57V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | 30POEX_4812-A |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 2.5 A |
| Efficiency | 85 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 12-SIP Module |
| Power (Watts) | 30 W |
| Size / Dimension Height | 1.06 in |
| Size / Dimension Length | 2.45 in |
| Size / Dimension Width | 0.58 in |
| Type | Isolated PoE (Power over Ethernet) Module |
| Voltage - Input (Max) | 57 V |
| Voltage - Input (Min) | 36 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 12 V |
