Specification	5452368

Color	Black
Contact Mating Finish	Tin
Contact Tail Length	0.138 in
Current - IEC	12 A
Current - UL	15 A
Features	Mating Flange
Header Orientation	Right Angle
Header Orientation Angle	90 °
Insulation Height	0.339 in
Mounting Type	Through Hole
Number of Levels	1
Number of Positions	19
Pitch	0.197 in
Positions Per Level	19
Termination Style	Solder
Type	Shrouded (4 Side), Male Pins, Header
Voltage - IEC	320 V
Voltage - UL	300 V
