JJP36250
ActiveSCHNEIDER ELECTRIC
MOLDED CASE CIRCUIT BREAKER 600V
JJP36250
ActiveSCHNEIDER ELECTRIC
MOLDED CASE CIRCUIT BREAKER 600V
Description
General part information
JJP36250
Circuit Breaker Thermal Magnetic 250A 600 V AC 250 V DC Toggle Chassis Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | JJP36250 |
|---|---|
| Actuator Type | Toggle |
| Approval Agency | UL, CSA |
| Breaker Type | Thermal Magnetic |
| Current Rating | 250 A |
| Illumination | None |
| Mounting Type | Chassis Mount |
| Number of Poles | 3 |
| Voltage Rating - AC | 600 VAC |
| Voltage Rating - DC | 250 VDC |
