CFM-A751BF-253-623-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 172X51.5MM 24VDC WIRE
CFM-A751BF-253-623-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 172X51.5MM 24VDC WIRE
Description
General part information
CFM-A751BF-253-623-20
Fan Tubeaxial 24VDC Rectangular/Rounded - 172mm L x 151.5mm H Ball 382.7 CFM (10.72m³/min) 3 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-A751BF-253-623-20 |
|---|---|
| Air Flow | 382.7 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 3.48 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Speed Sensor (Tach) |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Aluminum |
| Noise | 62.3 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 83.5 W |
| RPM | 5300 RPM |
| Size / Dimension Height | 151.5 mm |
| Size / Dimension Length | 172 mm |
| Size / Dimension Shape | Rectangular/Rounded |
| Static Pressure | 1.48 in H2O |
| Termination | 3 Wire Leads |
| Termination Leads Count | 3 |
| Termination Type | Wire Leads |
| Voltage - Rated | 24 VAC |
| Voltage Range (Max) | 26.4 VDC |
| Voltage Range (Min) | 21.6 VDC |
| Width | 51.5 mm |
