Specification	TLNK476M010R1500

Capacitance	47 µF
ESR (Equivalent Series Resistance)	1.5 Ohm
Features	General Purpose
Height - Seated (Max)	0.039 in
Manufacturer Size Code	K
Mounting Type	Surface Mount
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	1206 (3216 Metric)
Size / Dimension Length	0.126 in
Size / Dimension Width	0.063 in
Tolerance	20 %
Type	Molded
Voltage - Rated	10 V
