B82787C0104H002
ActiveEPCOS - TDK Electronics
CMC 100UH 150MA 2LN 5.8KOHM SMD
B82787C0104H002
ActiveEPCOS - TDK Electronics
CMC 100UH 150MA 2LN 5.8KOHM SMD
Description
General part information
B82787C0104H002
100 µH @ 100 kHz 2 Line Common Mode Choke Surface Mount 5.8 kOhms @ 10 MHz 150mA DCR 2Ohm
Technical Specifications
Parameters and characteristics for this part
| Specification | B82787C0104H002 |
|---|---|
| Current Rating (Max) | 150 mA |
| DC Resistance (DCR) (Max) | 2 Ohm |
| Filter Type | Signal Line |
| Height (Max) | 0.118 in |
| Impedance | 5.8 kOhms |
| Inductance | 100 µH |
| Mounting Type | Surface Mount |
| Number of Lines | 2 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -40 °C |
| Package Name | Horizontal |
| Pad Count | 4 PC Pad |
| Ratings | AEC-Q200 |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.126 in |
| Voltage Rating - DC | 50 V |
