BFC233629051
NRNDVishay Dale
SAFETY CAP, 0.22UF, CLASS X2, RADIAL ROHS COMPLIANT: YES
BFC233629051
NRNDVishay Dale
SAFETY CAP, 0.22UF, CLASS X2, RADIAL ROHS COMPLIANT: YES
Description
General part information
BFC233629051
0.22 µF Film Capacitor 310V 630V Polypropylene (PP), Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | BFC233629051 |
|---|---|
| Applications | RFI Suppression, EMI |
| Capacitance | 0.22 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 0.61 in |
| Lead Spacing | 0.591 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 110 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Ratings | X2 |
| Size / Dimension Length | 1.024 in |
| Size / Dimension Width | 0.236 in |
| Termination | PC Pins |
| Tolerance | 20 % |
| Voltage Rating - AC | 310 V |
| Voltage Rating - DC | 630 V |
