Specification	EVAL-AD5247DBZ

Contents	Board
Embedded	No
Function	Digital Potentiometer
Primary Attributes	128 Position, 1 Channel
Secondary Attributes	I2C Interface, I2C Interface(s)
Supplied Contents	Board(s)
Type	Data Acquisition
Utilized IC / Part	AD5247

AD5247 Series

Part	Mounting Type	Tolerance	Package Name	Resistance	Resistance - Wiper (Typ)	Number of Circuits	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Interface	Taper	Memory Type	Temperature Coefficient (Typ)	Number of Taps	Operating Temperature (Max)	Operating Temperature (Min)	Configuration	Package / Case
Analog Devices Inc./Maxim Integrated AD5247BKSZ100-RL7	Surface Mount	20 %	SC-70-6	100 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKSZ100-R2	Surface Mount	20 %	SC-70-6	100 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKSZ100-2RL7	Surface Mount	20 %	SC-70-6	100 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKSZ10-RL7	Surface Mount	20 %	SC-70-6	10 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKS100-RL7	Surface Mount		SC-70-6	100 kOhm		1	5.5 V	2.7 V	I2C		Volatile	45 ppm/°C	128	125 °C	-40 °C		6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKS5-R2	Surface Mount	30 %	SC-70-6	5 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKSZ5-RL7	Surface Mount	30 %	SC-70-6	5 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKS50-RL7	Surface Mount		SC-70-6	50 kOhm		1	5.5 V	2.7 V	I2C		Volatile	45 ppm/°C	128	125 °C	-40 °C		6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKSZ10-2RL7	Surface Mount	20 %	SC-70-6	10 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
Analog Devices Inc./Maxim Integrated AD5247BKS10-R2	Surface Mount	20 %	SC-70-6	10 kOhm	75 Ohm	1	5.5 V	2.7 V	I2C	Linear	Volatile	45 ppm/°C	128	125 °C	-40 °C	Rheostat	6-TSSOP SC-88 SOT-363
