3-1719040-1
ActiveTE Connectivity AMP Connectors
1X8 POS GET-MALE-CONNECTOR,CONN KIT
3-1719040-1
ActiveTE Connectivity AMP Connectors
1X8 POS GET-MALE-CONNECTOR,CONN KIT
Description
General part information
3-1719040-1
8 Position Housing, Housing for Male Terminals, Wire-to-Wire, 2.54 mm [.1 in] Centerline, Yellow, Wire & Cable, Signal, Get .64 Connector System
Technical Specifications
Parameters and characteristics for this part
| Specification | 3-1719040-1 |
|---|---|
| Color | Orange |
| Connector Type | Housing for Male Insert |
| Contact Termination | Crimp |
| Contact Type | Tab |
| Fastening Type | Locking Ramp |
| Features | Terminal Position Lock (TPA) |
| Insulation Material | Nylon, Glass Filled, Polyamide (PA) |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.1 in |
