A12.P25KHC.00259
ObsoleteApacer Memory America
SATA 2.5" SSD PLP 480GB WT
A12.P25KHC.00259
ObsoleteApacer Memory America
SATA 2.5" SSD PLP 480GB WT
Description
General part information
A12.P25KHC.00259
Solid State Drive (SSD) FLASH - NAND (TLC) 480GB SATA III 2.5" 5V
Technical Specifications
Parameters and characteristics for this part
| Specification | A12.P25KHC.00259 |
|---|---|
| Current - Max | 510 mA |
| Form Factor Size | 2.5 in |
| Memory Size | 480 GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Size / Dimension Height | 6.9 mm |
| Size / Dimension Length | 100 mm |
| Size / Dimension Width | 69.85 mm |
| Speed - Read | 555 MB/s |
| Speed - Write | 500 MB/s |
| Type | SATA III |
| Voltage - Supply | 5 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
