PD30ETRR60BPA2IO
ActiveCarlo Gavazzi Inc.
SENSOR: PHOTOELECTRIC; RANGE: 6M; PNP/NPN NO/NC; USUP: 10÷30VDC
PD30ETRR60BPA2IO
ActiveCarlo Gavazzi Inc.
SENSOR: PHOTOELECTRIC; RANGE: 6M; PNP/NPN NO/NC; USUP: 10÷30VDC
Description
General part information
PD30ETRR60BPA2IO
Retroreflective Optical Sensor 236.220" (6m) Push-Pull, NPN/PNP
Technical Specifications
Parameters and characteristics for this part
| Specification | PD30ETRR60BPA2IO |
|---|---|
| Adjustment Type | Adjustable, Potentiometer |
| Cable Length | 78.74 in |
| Connection Method | Cable |
| Ingress Protection | IP68, IP67, IP69K |
| Light Source | Red |
| Light Source Wavelength (Red) | 620 nm |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -25 °C |
| Output Configuration | PNP, NPN, Push-Pull |
| Response Time | 500 µs |
| Sensing Distance | 236.22 " |
| Sensing Method | Retroreflective |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 10 VDC |
