CFM-3010B-180-267-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 30X10.5MM 12VDC WIRE
CFM-3010B-180-267-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 30X10.5MM 12VDC WIRE
Description
General part information
CFM-3010B-180-267-20
Fan Tubeaxial 12VDC Square - 30mm L x 30mm H Ball 2.5 CFM (0.070m³/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-3010B-180-267-20 |
|---|---|
| Air Flow | 2.5 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 0.09 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Speed Sensor (Tach) |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 26.8 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 1.08 W |
| RPM | 8000 RPM |
| Size / Dimension Height | 30 mm |
| Size / Dimension Length | 30 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.08 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Voltage Range (Max) | 13.2 VDC |
| Voltage Range (Min) | 10.8 VDC |
| Width | 10.5 mm |
