RN122-4-02
ObsoleteTE Connectivity AMP Connectors
CMC 3.3MH 4A 2LN TH
RN122-4-02
ObsoleteTE Connectivity AMP Connectors
CMC 3.3MH 4A 2LN TH
Description
General part information
RN122-4-02
3.3 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 4A (Typ) DCR 48mOhm (Typ)
Technical Specifications
Parameters and characteristics for this part
| Specification | RN122-4-02 |
|---|---|
| Approval Agency | UR, VDE |
| Current Rating (Max) | 4 A |
| Current Rating (Typ) | 4 A |
| DC Resistance (DCR) (Max) | 48 mOhm |
| DC Resistance (DCR) (Typ) | 48 mOhm |
| Filter Type | Power Line |
| Height (Max) | 0.661 in |
| Inductance | 3.3 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 4 PC Pin, Horizontal |
| Package Leads | 4 Leads |
| Package Name | Horizontal |
| Size / Dimension Length | 1.102 in |
| Size / Dimension Width | 1.063 in |
| Voltage Rating - AC | 250 V |
