Description

General part information

3-1586040-2

PCB Mount Header, Vertical, Wire-to-Board, 2 Position, 4.2 mm [.165 in] Centerline, Fully Shrouded, Gold (Au), Through Hole - Solder, Power, Natural

Technical Specifications

Parameters and characteristics for this part

Specification3-1586040-2
Connector TypeHeader
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thickness - Mating30 µin
Contact Length - Post0.138 in
Contact MaterialBrass Alloy
Contact ShapeSquare
Contact TypeMale Pin
Current Rating9 A
Fastening TypeLocking Ramp
FeaturesBoard Lock
Insulation ColorNatural
Insulation Height0.5 in
Insulation MaterialNylon, Polyamide (PA)
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole
Number of Positions2
Number of Positions LoadedAll
Number of Rows2
Operating Temperature (Max)105 °C
Operating Temperature (Min)-40 °C
Row Spacing - Mating0.165 in
ShroudingShrouded - 4 Wall
StyleCable/Wire, Board
TerminationSolder
Voltage Rating600 V
