HGL26125
ActiveSCHNEIDER ELECTRIC
MOLDED CASE CIRCUIT BREAKER 600V
HGL26125
ActiveSCHNEIDER ELECTRIC
MOLDED CASE CIRCUIT BREAKER 600V
Description
General part information
HGL26125
Circuit Breaker Thermal Magnetic 125A 690 V AC 500 V DC Toggle Chassis Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | HGL26125 |
|---|---|
| Actuator Type | Toggle |
| Approval Agency | UL, CSA |
| Breaker Type | Thermal Magnetic |
| Current Rating | 125 A |
| Illumination | None |
| Mounting Type | Chassis Mount |
| Number of Poles | 2 |
| Voltage Rating - AC | 690 V |
| Voltage Rating - DC | 500 V |
