RER-S2C-A230

Active

Dinkle Corporation, USA

RELAY GEN PURPOSE SPDT 10A 230V

Search across all available documentation for this part.

Active

Dinkle Corporation, USA

RELAY GEN PURPOSE SPDT 10A 230V

Technical Specifications

Parameters and characteristics for this part

RELAY GEN PURPOSE SPDT 10A 230V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Features	Coil Resistance	Coil Voltage	Coil Current	Coil Type	Must Release Voltage	Contact Rating (Current)	Switching Voltage [Max]	Contact Form	Release Time	Relay Type	Operate Time	Mounting Type	Must Operate Voltage	Contact Material
Dinkle Corporation, USA RER-S2C-A230	70 °C	-55 °C	Lighted Indicator	4.43 kOhms	230 VAC	5.5 mA	Non Latching	69 VAC	10 A	30 VDC, 250 VAC	DPDT (2 Form C)	20 ms	General Purpose	20 ms	Socketable	184 VAC	Silver Nickel (AgNi)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay DPDT (2 Form C) 230VAC Coil Socketable
