Description

General part information

AMP POWER Series

PCB Mount Header, Vertical, Wire-to-Board, 4 Position, 6.5 mm [.255 in] Centerline, Fully Shrouded, Tin (Sn), Through Hole - Solder, Power Double Lock

Technical Specifications

Parameters and characteristics for this part

Specification179848-1
Connector TypeHeader
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Length - Post0.15 in
Contact MaterialCopper Alloy
Contact ShapeRectangular
Contact TypeTab
Current Rating0 A
Current RatingVaries by Wire Gauge
Fastening TypeLocking Ramp
FeaturesBoard Guide
Insulation ColorNatural
Insulation Height0.575 in
Insulation MaterialPolyamide (PA66), Nylon 6/6
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole
Number of Positions4
Number of Positions LoadedAll
Number of Rows2
Operating Temperature (Max)105 °C
Operating Temperature (Min)-30 °C
Pitch - Mating0.256 in
Row Spacing - Mating0.256 in
ShroudingShrouded - 4 Wall
StyleCable/Wire, Board
TerminationKinked Pin, Solder
