2882459
ObsoletePhoenix Contact
SPD TYPE 3 335VAC MCOV 1 POLE
2882459
ObsoletePhoenix Contact
SPD TYPE 3 335VAC MCOV 1 POLE
Description
General part information
2882459
SPD TYPE 3 335VAC MCOV 1 POLE
Technical Specifications
Parameters and characteristics for this part
| Specification | 2882459 |
|---|---|
| Approval Agency | CB, cUR, cURus, EAC, UR |
| Current - Discharge (Max) | 10 kA |
| Current - Discharge (Nom) | 1.5 kA |
| Current - Short Circuit Rating (SCCR) | 1.5 kA |
| Form | Module, Base |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Type | Type 3 |
| Voltage - Continuous Operating (Max) (MCOV) | 335 VAC |
| Voltage - Protection Level (VP) (2416) | 1.5 kV |
