C42-3021-40FT
ActiveCabling123
SM DUPLEX LC-FC 40FT FIBER CBL
C42-3021-40FT
ActiveCabling123
SM DUPLEX LC-FC 40FT FIBER CBL
Description
General part information
C42-3021-40FT
Cable Fiber Optic LC Duplex To FC (2) SMF 40.0' (12.2m)
Technical Specifications
Parameters and characteristics for this part
| Specification | C42-3021-40FT |
|---|---|
| 1st Connector | LC Duplex |
| 2nd Connector | FC |
| 2nd Connector Count | 2 pcs |
| Cable Diameter | 0.08 " |
| Color - Cable | Yellow |
| Color - Connectors | Blue |
| Fiber Type | SMF |
| Insertion Loss | 0.3 dB |
| Length - Overall | 40 ft |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -20 °C |
| Ratings | LSZH |
| Return Loss | 50 dB |
| Type | Duplex |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
