MPMM24SMBZ-10
ActivePasternack
MPO W/ PINS TO MPO W/ PINS, 24 F
MPMM24SMBZ-10
ActivePasternack
MPO W/ PINS TO MPO W/ PINS, 24 F
Description
General part information
MPMM24SMBZ-10
Cable Fiber Optic MPO To MPO 9/125 32.8' (10.0m)
Technical Specifications
Parameters and characteristics for this part
| Specification | MPMM24SMBZ-10 |
|---|---|
| 1st Connector | MPO |
| 2nd Connector | MPO |
| Color - Cable | Yellow |
| Fiber Cladding Diameter | 125 µm |
| Fiber Core Diameter | 9 µm |
| Jacket (Insulation) Material | Low Smoke Zero Halogen (LSZH) |
| Length - Overall | 32.8 ft |
| Type | OS2, Singlemode |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
