SENS'IT DISCOVERY 3.4

Active

Sigfox

SENS'IT RC4 AUSTRALIA SINGAPORE

Search across all available documentation for this part.

Active

Sigfox

SENS'IT RC4 AUSTRALIA SINGAPORE

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	SENS'IT DISCOVERY 3.4	SENS'IT DISCOVERY Series

Applications	General Purpose, IoT Finished Device	General Purpose, IoT Finished Device
Data Rate (Max)	600 bps	100 - 600 bps
Features	IP54, Rechargeable Battery	IP54, Rechargeable Battery
Frequency [Max]	925 MHz	869.7 - 925 MHz
Frequency [Min]	920 MHz	868 - 922.2 MHz
Function	Sensor	Sensor
Interface	USB	USB
Modulation or Protocol	Sigfox	Sigfox
Power - Output	22 dBm	10 - 22 dBm
Sensitivity	-126 dBm	-126 - -124 dBm

SENS'IT RC1 EUROPE

Part	Modulation or Protocol	Sensitivity	Applications	Power - Output	Frequency [Max]	Frequency [Min]	Interface	Data Rate (Max)	Function	Features
Sigfox SENS'IT DISCOVERY 3.1	Sigfox	-124 dBm	General Purpose, IoT Finished Device	14 dBm	869.7 MHz	868 MHz	USB	100 bps	Sensor	IP54, Rechargeable Battery
Sigfox SENS'IT DISCOVERY 3.2	Sigfox	-126 dBm	General Purpose, IoT Finished Device	22 dBm	908 MHz	902 MHz	USB	600 bps	Sensor	IP54, Rechargeable Battery
Sigfox SENS'IT DISCOVERY 3.3	Sigfox	-126 dBm	General Purpose, IoT Finished Device	10 dBm	923.2 MHz	922.2 MHz	USB	100 bps	Sensor	IP54, Rechargeable Battery
Sigfox SENS'IT DISCOVERY 3.4	Sigfox	-126 dBm	General Purpose, IoT Finished Device	22 dBm	925 MHz	920 MHz	USB	600 bps	Sensor	IP54, Rechargeable Battery

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF Sensor 920MHz ~ 925MHz Sigfox USB 600bps
