GoldMax 300 Comm C0G Series

...

Part	Applications	Lead Spacing	Mounting Type	Height - Seated (Max)	Lead Style	Operating Temperature (Max)	Operating Temperature (Min)	Tolerance	Temperature Coefficient	Features	Voltage - Rated	Capacitance	Package / Case	Size / Dimension Length	Size / Dimension Width
KEMET C325C432F3G5TA	General Purpose	0.2 in	Through Hole	0.3 in	Formed Leads - Kinked	125 °C	-55 °C	1 %	C0G NP0	Low ESL	25 VAC	4300 pF	Radial	0.2 in	0.125 in
KEMET C322C124K5G5TA	General Purpose	0.2 in	Through Hole	0.26 in	Formed Leads	125 °C	-55 °C	10 %	C0G NP0	Low ESL	50 V	0.12 µF	Radial	0.2 in	0.125 in
KEMET C321C331KAG5TA	General Purpose	0.25 in	Through Hole	0.26 in	Formed Leads	125 °C	-55 °C	10 %	C0G NP0	Low ESL	250 V	330 pF	Radial	0.2 in	0.125 in
KEMET C331C273FAG5TA
KEMET C323C154J5G5TA	General Purpose	0.2 in	Through Hole	0.3 in	Formed Leads	125 °C	-55 °C	5 %	C0G NP0	Low ESL	50 V	0.15 µF	Radial	0.2 in	0.125 in
KEMET C328C752K3G5TA	General Purpose	0.2 in	Through Hole	0.3 in	Formed Leads	125 °C	-55 °C	10 %	C0G NP0	Low ESL	25 VAC	7500 pF	Radial	0.2 in	0.125 in
KEMET C321C202J3G5TA	General Purpose	0.25 in	Through Hole	0.26 in	Formed Leads	125 °C	-55 °C	5 %	C0G NP0	Low ESL	25 VAC	2000 pF	Radial	0.2 in	0.125 in
KEMET C318C471J3G5TA	General Purpose	0.2 in	Through Hole	0.235 in	Formed Leads	125 °C	-55 °C	5 %	C0G NP0	Low ESL	25 VAC	470 pF	Radial	0.15 in	0.1 in
KEMET C315C240FAG5TA	General Purpose	0.1 in	Through Hole	0.183 in	Straight	125 °C	-55 °C	1 %	C0G NP0	Low ESL	250 V	24 pF	Radial	0.15 in	0.1 in
KEMET C330C511FAG5TA	General Purpose	0.2 in	Through Hole	0.36 in	Straight	125 °C	-55 °C	1 %	C0G NP0	Low ESL	250 V	510 pF	Radial	0.28 in	0.16 in
