10LPCV2440

Active

Sensata-Crydom

SSR RELAY SPST-NO 40A 20-300V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 40A 20-300V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State SPST-NO (1 Form A) Module

Technical documentation and resources

Specification	10LPCV2440	10LPCV Series

Approval Agency	CE	CE
Load Current	40 A	40 - 110 A
Mounting Type	Chassis Mount	Chassis Mount
Operating Temperature [Max]	80 C	80 C
Operating Temperature [Min]	-30 ░C	-30 ░C
Output Type	AC, Proportional Control	AC, Proportional Control
Package / Case	Module	Module
Termination Style	Screw Terminal, Quick Connect	Screw Terminal, Quick Connect
Termination Style	0.25 in	0.25 in
Voltage - Input [Max]	10 V	10 V
Voltage - Input [Min]	0 V	0 V
Voltage - Load [Max]	300 V	300 V
Voltage - Load [Min]	20 V	20 V

Part	Load Current	Voltage - Load [Max]	Voltage - Load [Min]	Mounting Type	Termination Style	Termination Style	Voltage - Input [Max]	Voltage - Input [Min]	Approval Agency	Output Type	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]
Sensata-Crydom 10LPCV2440	40 A	300 V	20 V	Chassis Mount	Quick Connect, Screw Terminal	0.25 in	10 V	0 V	CE	AC, Proportional Control	Module	-30 ░C	80 C
Sensata-Crydom 10LPCV24110	110 A	300 V	20 V	Chassis Mount	Quick Connect, Screw Terminal	0.25 in	10 V	0 V	CE	AC, Proportional Control	Module	-30 ░C	80 C
