2PASM-07G.50

Active

Fraenkische USA, LP

SLIT WRAP 0.248" X 164' GRAY

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

2PASM-07G.50

Active

Fraenkische USA, LP

SLIT WRAP 0.248" X 164' GRAY

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	2PASM-07G.50	2PASM Series

Color	Gray	Gray, Black
Diameter - Inside, Non-Expanded	-	27.3 - 43.1 mm
Diameter - Inside, Non-Expanded	-	1.075 "
Diameter - Inside, Non-Expanded	-	20.2 mm
Diameter - Inside, Non-Expanded	-	0.795 in
Diameter - Inside, Non-Expanded [diameter]	6.3 mm	0.433 - 87.5 mm
Diameter - Inside, Non-Expanded [diameter]	0.248 in	0.248 - 3.445 "
Diameter - Outside, Non-Expanded	-	102.5 mm
Diameter - Outside, Non-Expanded	-	18.7 mm
Diameter - Outside, Non-Expanded [diameter]	10 mm	4.035 - 79.8 in
Diameter - Outside, Non-Expanded [diameter]	0.394 in	0.394 - 3.142 in
Environment Protection	Weather Resistant	Weather Resistant
Length	-	10 m
Length	-	32.81 ft
Length [x]	50 m	25 - 50 m
Length [x]	164 ft	82.02 - 164 ft
Operating Temperature [Max]	120 °C	120 °C
Operating Temperature [Min]	-45 °C	-45 °C
Type	Slit Wrap	Slit Wrap
Type Attributes	Slit Harness	Slit Harness

2PASM Series

SLIT WRAP 3.445" X 32.81' GRAY

Part	Environment Protection	Operating Temperature [Max]	Operating Temperature [Min]	Type Attributes	Length	Length	Type	Diameter - Inside, Non-Expanded [diameter]	Diameter - Inside, Non-Expanded [diameter]	Diameter - Outside, Non-Expanded [diameter]	Diameter - Outside, Non-Expanded [diameter]	Color	Length [x]	Length [x]	Diameter - Outside, Non-Expanded [diameter]	Diameter - Outside, Non-Expanded	Diameter - Inside, Non-Expanded	Diameter - Inside, Non-Expanded	Diameter - Inside, Non-Expanded [custom]	Diameter - Inside, Non-Expanded [custom]
Fraenkische USA, LP 2PASM-100G.10	Weather Resistant	120 °C	-45 °C	Slit Harness	10 m	32.81 ft	Slit Wrap	3.445 "	87.5 mm	102.5 mm	4.035 in	Gray
Fraenkische USA, LP 2PASM-14G.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap	0.52 in	13.2 mm			Gray	50 m	164 ft	0.736 in	18.7 mm
Fraenkische USA, LP 2PASM-11G.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap		0.433 in, 11 mm		16.1 mm	Gray	50 m	164 ft	0.634 "
Fraenkische USA, LP 2PASM-10B.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap	0.346 in	8.8 mm		13.5 mm	Black	50 m	164 ft	0.531 "
Fraenkische USA, LP 2PASM-29B.25	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap				35.5 mm	Black	25 m	82.02 ft	1.398 in		27.3 mm	1.075 "
Fraenkische USA, LP 2PASM-20G.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap				25.7 mm	Gray	50 m	164 ft	1.012 in				20.2 mm	0.795 in
Fraenkische USA, LP 2PASM-37B.25				Slit Harness			Slit Wrap	1.28 in	32.5 mm		43.2 mm	Black	25 m	82.02 ft	1.701 in
Fraenkische USA, LP 2PASM-23G.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap					Gray	50 m	164 ft
Fraenkische USA, LP 2PASM-16G.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap	0.63 "	16 mm		21.5 mm	Gray	50 m	164 ft	0.846 in
Fraenkische USA, LP 2PASM-23B.50	Weather Resistant	120 °C	-45 °C	Slit Harness			Slit Wrap					Black	50 m	164 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	54	$ 89.12

Description

General part information

2PASM Series

Slit Wrap 0.394" (10.00mm) X 164' (50.00m) Gray
