| Approval Agency | TUV, VDE, CSA, UR | BSI, cURus, VDE, UR, TUV, CSA |
| Circuit | - | SPST-NO (1 Form A) x 2, SPST-NC (1 Form B), SPST-NO, SPST-NC, SPST-NC (1 Form B) x 2 |
| Coil Current | 72 mA | 8.3 - 120 mA |
| Coil Insulation | Class E | Class E |
| Coil Resistance | 69.4 Ohms | 1.62 - 720 Ohms |
| Coil Type | Non Latching | Non Latching |
| Coil Voltage | 5 VDC | 4 - 24 VDC |
| Contact Form | SPDT (1 Form C) | DPDT (2 Form C), SPST-NO (1 Form A), SPDT (1 Form C), 4PDT (4 Form C) |
| Contact Material | Silver Alloy | Silver (Ag), Gold (Au), Silver Nickel (AgNi), Silver Alloy |
| Contact Rating (Current) | 10 A | 1 - 10 A |
| Load - Max Switching | 1000 W, 2500 VA | 90 - 2500 W |
| Load - Max Switching | - | 60 - 440 VA |
| Load Current | - | 1 - 700 mA |
| Mounting Type | Through Hole | Through Hole, Chassis Mount |
| Must Operate Voltage | 3.5 VDC | 2.1 - 18 VDC |
| Must Release Voltage | 0.5 VDC | 0.22 - 1.2 VDC |
| On-State Resistance (Max) | - | 1 - 700 Ohms |
| Operate Time | 10 ms | 3 - 10 ms |
| Operating Temperature [Max] | 70 °C | 70 - 85 °C |
| Operating Temperature [Min] | -40 °C | -40 - -20 °C |
| Output Type | - | DC, AC, AC, Zero Cross, DC (RF) |
| Package / Case | - | 4-DIP, 6-DIP, 4-SIP, 8-DIP, Hockey Puck |
| Package / Case | - | 0.3 - 10.16 in |
| Package / Case | - | 0.3 - 10.16 mm |
| Package / Case | - | 7.62 mm |
| Relay Type | General Purpose | General Purpose, Telecom |
| Release Time | 10 ms | 2 - 10 ms |
| Seal Rating | Sealed - Fully | Sealed - Fully |
| Supplier Device Package | - | 4-DIP, 6-DIP, 4-SIL, 8-DIP |
| Switching Voltage | 250 VAC, 100 VDC | 30 - 277 VDC |
| Termination Style | PC Pin | PC Pin, Screw Terminal |
| Voltage - Input | - | 1.14 - 2.3 VDC |
| Voltage - Input | - | 32 V |
| Voltage - Input | - | 4 V |
| Voltage - Load | - | 0 - 75 V |
| Voltage - Load | - | 60 - 1500 V |
