Description
General part information
DF10S
Bridge Rectifier Single Phase Standard 1 kV Surface Mount DFS
Technical Specifications
Parameters and characteristics for this part
| Specification | DF10S |
|---|---|
| Current - Average Rectified (Io) | 1 A |
| Current - Reverse Leakage | 5 µA |
| Diode Type | Single Phase |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 4-SMD, Gull Wing |
| Package Name | DFS |
| Technology | Standard |
| Voltage - Forward (Vf) (Max) | 1.1 V |
| Voltage - Peak Reverse (Max) | 1000 V |
