PDSE1-S15-S15-S
CUI Inc.
DC-DC 1.5KV ISOLATED, 1 W, 13.5~
Deep-Dive with AI
Search across all available documentation for this part.
PDSE1-S15-S15-S
CUI Inc.
DC-DC 1.5KV ISOLATED, 1 W, 13.5~
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PDSE1-S15-S15-S |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Current - Output (Max) [Max] | 67 mA |
| Efficiency | 81 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 105 C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SIP Module |
| Size / Dimension [x] | 11.6 mm |
| Size / Dimension [x] | 0.46 in |
| Size / Dimension [y] | 6 mm |
| Size / Dimension [y] | 0.24 " |
| Size / Dimension [z] | 0.4 " |
| Size / Dimension [z] | 10.2 mm |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 16.5 V |
| Voltage - Input (Min) [Min] | 13.5 V |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 2.77 | |
| 5 | $ 2.61 | |||
| 10 | $ 2.54 | |||
| 25 | $ 2.46 | |||
| 50 | $ 2.40 | |||
Description
General part information
PDSE1-S15-S15-S
Isolated Module DC DC Converter 1 Output 15V 67mA 13.5V - 16.5V Input
Documents
Technical documentation and resources
No documents available
