XEP4E1FDA454J03
ActiveSCHNEIDER ELECTRIC
SWITCH LIMIT SPDT 1.5A 240V
XEP4E1FDA454J03
ActiveSCHNEIDER ELECTRIC
SWITCH LIMIT SPDT 1.5A 240V
Description
General part information
XEP4E1FDA454J03
Switch SPDT Chassis Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | XEP4E1FDA454J03 |
|---|---|
| Actuator Type | Lever, Straight |
| Circuit | SPDT |
| Current Rating | 100 mA, 1.5 A |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mechanical Life (Cycles) | 2000000 Cycles |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Switch Function | On-Mom |
| Termination Style | Cable Leads |
| Voltage Rating - AC | 240 V |
| Voltage Rating - DC | 250 VDC |
