Part	Overall Contact Length	Contact Material	Termination	Contact Finish - Mating	Contact Shape	Insulation Height	Voltage Rating	Contact Length - Post	Insulation Material	Insulation Color	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Fastening Type	Style	Contact Finish - Post	Connector Type	Pitch - Mating	Number of Positions	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Length - Mating	Material Flammability Rating	Contact Type	Number of Rows	Shrouding	Applications	Contact Finish Thickness - Post
TE Connectivity AMP Connectors 104178-1	0.32 in	Copper Alloy	Solder	Gold	Square	0.1 in	30 V	0.1 in	Thermoplastic	Black	Through Hole	105 °C	-65 °C	Push-Pull	Board Board or Cable	Tin-Lead	Header	0.05 in	4	All	30 µin	0.12 in	UL94 V-0	Male Pin	1	Unshrouded	Automotive General Purpose Medical Telecommunications	150 µin

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
