BCH2MM0522CF6C
ActiveSCHNEIDER ELECTRIC
130MM, 500W, IP65, WO KEY, BRK,
BCH2MM0522CF6C
ActiveSCHNEIDER ELECTRIC
130MM, 500W, IP65, WO KEY, BRK,
Description
General part information
BCH2MM0522CF6C
AC Motor Servomotor 3000 RPM 500W Absolute 220VAC
Technical Specifications
Parameters and characteristics for this part
| Specification | BCH2MM0522CF6C |
|---|---|
| Diameter - Shaft | 0.87 in |
| Encoder Type | Absolute |
| Features | Brake, Oil Seal |
| Function | Servomotor |
| Length - Shaft and Bearing | 1.772 in |
| Mounting Hole Spacing | 4.33 in |
| Operating Temperature (Max) | 40 °C |
| Operating Temperature (Min) | 0 °C |
| Power - Rated | 500 W |
| RPM | 3000 RPM |
| Size / Dimension Length | 5.12 in |
| Size / Dimension Shape | Square |
| Size / Dimension Width | 5.12 in |
| Termination Style | Connector |
| Torque - Rated (mNm) | 2390 mNm |
| Torque - Rated (oz-in) | 338.5 oz-in |
| Type | AC Motor |
| Voltage - Rated | 220 VAC |
