Specification	AMI-M11J-6-10-B

Applications	General Purpose
Configuration	Single Stage
Current	6 A
Filter Type	Single Phase
Frequency - Operating	60Hz, 50Hz
Frequency - Operating (Max)	60 Hz
Frequency - Operating (Min)	50 Hz
Inductance	495 µH
Mounting Type	Chassis Mount
Operating Temperature (Max)	40 °C
Operating Temperature (Min)	-10 °C
Termination Style	Threaded Post (8-32), Threaded Post
Thread Size	8-32
Voltage - Rated AC	250 V

AMI-M11J Series

Part	Inductance	Configuration	Mounting Type	Frequency - Operating (Min)	Frequency - Operating	Frequency - Operating (Max)	Termination Style	Filter Type	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Rated AC	Current	Applications
Altran Magnetics, LLC AMI-M11J-3-3-B-2	1.76 mH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Wire Leads	Single Phase	-10 °C	40 °C	250 V	3 A	General Purpose
Altran Magnetics, LLC AMI-M11J-3-3-B-1	1.76 mH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Wire Leads	Single Phase	-10 °C	40 °C	250 V	3 A	General Purpose
Altran Magnetics, LLC AMI-M11J-3-1-B-1	1.86 mH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Wire Leads	Single Phase	-10 °C	40 °C	250 V	1 A	General Purpose
Altran Magnetics, LLC AMI-M11J-3-10-B-1	495 µH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Wire Leads	Single Phase	-10 °C	40 °C	250 V	10 A	General Purpose
Altran Magnetics, LLC AMI-M11J-1-20-B-1	440 µH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Quick Connect	Single Phase	-10 °C	40 °C	250 V	20 A	General Purpose
Altran Magnetics, LLC AMI-M11J-1-2-B-1	539 µH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Quick Connect	Single Phase	-10 °C	40 °C	250 V	2 A	General Purpose
Altran Magnetics, LLC AMI-M11J-1-2-B-2	539 µH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Quick Connect	Single Phase	-10 °C	40 °C	250 V	2 A	General Purpose
Altran Magnetics, LLC AMI-M11J-1-1-B-1	1.86 mH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Quick Connect	Single Phase	-10 °C	40 °C	250 V	1 A	General Purpose
Altran Magnetics, LLC AMI-M11J-1-3-B-2	1.76 mH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Quick Connect	Single Phase	-10 °C	40 °C	250 V	3 A	General Purpose
Altran Magnetics, LLC AMI-M11J-1-10-B-2	495 µH	Single Stage	Chassis Mount	50 Hz	50Hz 60Hz	60 Hz	Quick Connect	Single Phase	-10 °C	40 °C	250 V	10 A	General Purpose

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Datasheet

AMI-M11J-6-10-B | Datasheet
