197D20
ActiveHammond Manufacturing
FIXED IND 2MH 20A 0.049OHM SMD
197D20
ActiveHammond Manufacturing
FIXED IND 2MH 20A 0.049OHM SMD
Description
General part information
197D20
2 mH Unshielded Powdered Iron Core Inductor 20 A 49mOhm Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | 197D20 |
|---|---|
| Current Rating | 20 A |
| DC Resistance (DCR) | 49 mOhm |
| Frequency - Self Resonant | 218 kHz |
| Height - Seated (Max) | 162.56 mm |
| Inductance | 2 mH |
| Material - Core | Carbonyl Powder |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 6.1 in |
| Size / Dimension Width | 4.38 in |
| Tolerance | 15 % |
| Type | Powdered Iron Core |
