214916-E
ActiveTE Connectivity AMP Connectors
BOARD TO BOARD & MEZZANINE CONNECTORS 5-PIN,VERTICAL,SMT/THR
214916-E
ActiveTE Connectivity AMP Connectors
BOARD TO BOARD & MEZZANINE CONNECTORS 5-PIN,VERTICAL,SMT/THR
Description
General part information
- Series
PCB Mount Plug, Vertical, Board-to-Board, 5 Position, 2 mm [.079 in] Centerline, Fully Shrouded, Through Hole - Solder, ERNI MicroSpeed Power Modules
Technical Specifications
Parameters and characteristics for this part
| Specification | 214916-E |
|---|---|
| Connector Type | Array, Male Pins |
| Contact Finish | Gold |
| Features | Board Guide, Pick and Place, Ground Bus (Plane) |
| Height Above Board | 0.187 in |
| Mounting Type | Surface Mount, Through Hole |
| Number of Positions | 5 |
| Number of Rows | 1 |
| Pitch | 0.079 in |
