TE Series

Part	Polarization	Voltage - Rated	Tolerance (Negative)	Tolerance (Positive)	Mounting Type	Applications	Size / Dimension Diameter	Size / Dimension Length	Capacitance	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Lifetime
Vishay Dale TE1302-E3	Polar	50 V	10 %	75 %	Through Hole	General Purpose	0.248 in	0.512 in	3 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1203.5	Polar	25 VAC	10 %	75 %	Through Hole	General Purpose	0.248 in	0.512 in	8 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1207	Polar	25 VAC	10 %	75 %	Through Hole	General Purpose	0.315 in	0.689 in	25 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1500-E3	Polar	150 VAC	10 %	50 %	Through Hole	General Purpose	0.248 in	0.512 in	1 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1202ET	Polar	25 VAC	10 %	75 %	Through Hole	General Purpose	0.248 in	0.512 in	5 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1202E	Polar	25 VAC	10 %	75 %	Through Hole	General Purpose	0.248 in	0.512 in	5 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1162-E3	Polar	16 V	10 %	75 %	Through Hole	General Purpose	0.354 in	0.807 in	100 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1303.3	Polar	50 V	10 %	75 %	Through Hole	General Purpose	0.248 in	0.689 in	8 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1160	Polar	16 V	10 %	75 %	Through Hole	General Purpose	0.315 in	0.689 in	50 µF	-40 °C	105 °C	Axial Can	2000 Hrs
Vishay Dale TE1164.5-E3	Polar	16 V	10 %	75 %	Through Hole	General Purpose	0.354 in	1.26 in	250 µF	-40 °C	105 °C	Axial Can	2000 Hrs
