Description
General part information
PFI25-8DP2
SENSOR PROX INDUCTIVE 8MM MODULE
Technical Specifications
Parameters and characteristics for this part
| Specification | PFI25-8DP2 |
|---|---|
| Indicator | LED |
| Ingress Protection | IP67 |
| Material - Body | Polyphenylene Sulfide (PPS) |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Output Type | 3-Wire, PNP-NC |
| Package / Case | Module |
| Response Frequency | 200 Hz |
| Sensing Distance | 0.315 " |
| Sensor Type | Inductive |
| Termination Style | Cable Leads |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 10 VDC |
