QT20.481

Active

PULS, LP

AC/DC DIN RAIL SUPPLY 48V 480W

Search across all available documentation for this part.

Active

PULS, LP

AC/DC DIN RAIL SUPPLY 48V 480W

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	QT20.481	QT20 Series

AC Voltage - Input [Max]	552 VAC	552 VAC
AC Voltage - Input [Min]	323 VAC	323 VAC
Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CSA, EAC, ABS, DNV GL, IEC, UL	SEMI, DNV GL, CSA, EAC, UL, ABS, IEC
Current - Output (Max) [Max]	10 A	10 - 20 A
Efficiency	95.4 %	94.6 - 95.4 %
Features	PFC, Adjustable Output, Load Sharing	PFC, Conformal Coating, Adjustable Output, Load Sharing
Input Type	AC	AC
Number of Outputs	1	1
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-10 °C	-10 °C
Power (Watts)	480 W	480 W
Size / Dimension [x]	5 in	5 in
Size / Dimension [x]	127 mm	127 mm
Size / Dimension [y]	2.56 "	2.56 "
Size / Dimension [y]	65 mm	65 mm
Size / Dimension [z]	4.88 "	4.88 "
Size / Dimension [z]	124 mm	124 mm
Standard Number	61010-2-201, 60950-1, 508, Class I Div 2	61010-2-201, Class I Div 2, 508, F47, 60950-1
Voltage - Isolation	500 V	500 V
Voltage - Output 1	48 V	24 - 48 V

AC/DC DIN RAIL SUPPLY 24V 480W

Part	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Features	Efficiency	Voltage - Output 1	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Voltage - Isolation	Number of Outputs	Input Type	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Approval Agency	Standard Number
PULS, LP QT20.241-C1	20 A	4.88 "	2.56 "	65 mm	5 in	127 mm	124 mm	Adjustable Output, Conformal Coating, Load Sharing, PFC	94.8 %	24 V	552 VAC	323 VAC	500 V	1	AC	480 W	-10 °C	70 °C	ITE (Commercial)
PULS, LP QT20.241	20 A	4.88 "	2.56 "	65 mm	5 in	127 mm	124 mm	Adjustable Output, Load Sharing, PFC	95 %	24 V	552 VAC	323 VAC	500 V	1	AC	480 W	-10 °C	70 °C	ITE (Commercial)	ABS, CSA, DNV GL, EAC, IEC, SEMI, UL	508, 60950-1, 61010-2-201, Class I Div 2, F47
PULS, LP QT20.481	10 A	4.88 "	2.56 "	65 mm	5 in	127 mm	124 mm	Adjustable Output, Load Sharing, PFC	95.4 %	48 V	552 VAC	323 VAC	500 V	1	AC	480 W	-10 °C	70 °C	ITE (Commercial)	ABS, CSA, DNV GL, EAC, IEC, UL	508, 60950-1, 61010-2-201, Class I Div 2
PULS, LP QT20.361	13.3 A	4.88 "	2.56 "	65 mm	5 in	127 mm	124 mm	Adjustable Output, Load Sharing, PFC	94.6 %	36 V	552 VAC	323 VAC	500 V	1	AC	480 W	-10 °C	70 °C	ITE (Commercial)	ABS, CSA, DNV GL, EAC, IEC, UL	508, 60950-1, 61010-2-201, Class I Div 2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 702.00

General part information

AC/DC DIN RAIL SUPPLY 48V 480W

Technical documentation and resources
