927357-1

Active

TE Connectivity AMP Connectors

FF 110 2P HOUSING PA66 NATURAL

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

FF 110 2P HOUSING PA66 NATURAL

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	927357-1	927357 Series

	-	-
Color	Natural	Natural
For Use With/Related Products	Quick Connects	Quick Connects
For Use With/Related Products	0.11 in	0.11 in
For Use With/Related Products	2.79 mm	2.79 mm
Gender	Female, Receptacle	Female, Receptacle
Material	Polyamide (PA66), Nylon 6/6	Polyamide (PA66), Nylon 6/6
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Note	Contacts Not Included	Contacts Not Included
Number of Positions	2	2
Stacking Direction	Side to Side	Side to Side
Style	Housing	Housing
Terminal Size	0.11 in	0.11 in
Terminal Size	2.79 mm	2.79 mm
Terminal Type	Disconnect, Quick Connect	Disconnect, Quick Connect

FF 110 2P HOUSING PA66 BLACK

Part	For Use With/Related Products	For Use With/Related Products	For Use With/Related Products	Mounting Type	Stacking Direction	Number of Positions	Terminal Size	Terminal Size	Color	Material	Style	Gender	Terminal Type	Note
TE Connectivity AMP Connectors 927357-2
TE Connectivity AMP Connectors 927357-1	Quick Connects	0.11 in	2.79 mm	Free Hanging (In-Line)	Side to Side	2	0.11 in	2.79 mm	Natural	Polyamide (PA66), Nylon 6/6	Housing	Female, Receptacle	Disconnect, Quick Connect	Contacts Not Included

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	7000	$ 0.27

General part information

2 Position Housing Connector Female, Receptacle Natural 0.110" (2.79mm)

Technical documentation and resources
