1989502
ActivePhoenix Contact
TERM BLK 8POS SIDE ENTRY 5MM PCB
1989502
ActivePhoenix Contact
TERM BLK 8POS SIDE ENTRY 5MM PCB
Description
General part information
1989502
8 Position Wire to Board Terminal Block Horizontal with Board 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1989502 |
|---|---|
| Color | Black |
| Current | 18 A |
| Features | Interlocking (Side) |
| Housing Material | Nylon, Polyamide, PA |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch | 0.197 in |
| Positions Per Level | 8 |
| Screw Thread | M2.6 |
| Torque - Screw (Maximum) | 0.4 Nm |
| Torque - Screw (Minimum) | 0.35 Nm |
| Voltage | 300 V |
| Wire Gauge (AWG) (Max) | 26 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
| Wire Termination | Screw |
