Specification	3RT10762AP36

Coil Power	920 W
Coil Voltage (Max)	240 VAC
Coil Voltage (Min)	220 VAC
Coil Voltage (Type)	DC, AC
Contact Form	A, PST-NO, Form, 3
Contact Rating (Current)	500 A
Features	Auxiliary Contacts
Mounting Type	Chassis Mount, DIN Rail
Operate Time	100 ms
Operating Temperature (Max)	60 °C
Operating Temperature (Min)	-25 °C
Pin Count	3 pins
Release Time	100 ms
Switching Voltage AC (Max)	1000 VAC
Termination Style	Screw Terminal

3RT1076 Series

Part	Release Time	Operate Time	Coil Power	Coil Voltage (Max)	Coil Voltage (Type)	Coil Voltage (Min)	Operating Temperature (Min)	Operating Temperature (Max)	Termination Style	Mounting Type	Features	Contact Rating (Current)	Switching Voltage AC (Max)	Pin Count	Contact Form
Siemens 3RT10766SF363PA0	130 ms	75 ms	800 W	127 VAC/DC	AC DC	96 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766SF36	130 ms	75 ms	800 W	127 VAC/DC	AC DC	96 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766NP363PA0				277 VAC	AC DC	200 VAC/DC						500 A
Siemens 3RT10766AM36	100 ms	100 ms	920 W	220 VAC/DC	AC DC	200 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766AV36	100 ms	100 ms	920 W	420 VAC/DC	AC DC	380 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766PF35	100 ms	90 ms	800 W	127 VAC/DC	AC DC	96 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766PP35	100 ms	90 ms	800 W	277 VAC	AC DC	200 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766SP36	130 ms	75 ms	800 W	277 VAC	AC DC	200 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766AS36	100 ms	100 ms	920 W	550 VAC/DC	AC DC	500 VAC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
Siemens 3RT10766SP363PA0	130 ms	75 ms	800 W	277 VAC	AC DC	200 VAC/DC	-25 °C	60 °C	Screw Terminal	Chassis Mount DIN Rail	Auxiliary Contacts	500 A	1000 VAC	3 pins	3 A Form PST-NO
