MAXM17626AMB+T
ActiveAnalog Devices Inc./Maxim Integrated
2.7V TO 5.5V, 600MA USLIC POWER
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXM17626AMB+T
ActiveAnalog Devices Inc./Maxim Integrated
2.7V TO 5.5V, 600MA USLIC POWER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM17626AMB+T | MAXM17626 Series |
|---|---|---|
| Applications | ITE (Commercial) | ITE (Commercial) |
| Control Features | Active Low, Enable | Active Low, Enable |
| Current - Output (Max) [Max] | 600 mA | 600 mA |
| Features | Remote On/Off, Adjustable Output | Adjustable Output, Remote On/Off |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Outputs | 1 | 1 |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 10-SMD Module | 10-SMD Module |
| Size / Dimension [x] | 0.1 in | 0.1 in |
| Size / Dimension [x] | 2.6 mm | 2.6 mm |
| Size / Dimension [y] | 0.08 " | 0.08 " |
| Size / Dimension [y] | 2.1 mm | 2.1 mm |
| Size / Dimension [z] | 1.3 mm | 1.3 mm |
| Size / Dimension [z] | 0.05 in | 0.05 in |
| Supplier Device Package | 10-eMGA | 10-eMGA |
| Supplier Device Package [x] | 2.6 | 2.6 |
| Supplier Device Package [y] | 2.1 | 2.1 |
| Type | Non-Isolated PoL Module | Non-Isolated PoL Module |
| Voltage - Input (Max) [Max] | 5.5 V | 5.5 V |
| Voltage - Input (Min) [Min] | 2.7 V | 2.7 V |
| Voltage - Output 1 [Max] | 3.3 V | 3.3 V |
| Voltage - Output 1 [Min] | 0.8 V | 0.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 5.41 | |
| 10 | $ 3.62 | |||
| 25 | $ 3.16 | |||
| 100 | $ 2.64 | |||
| 250 | $ 2.39 | |||
| 500 | $ 2.23 | |||
| 1000 | $ 2.10 | |||
| Digi-Reel® | 1 | $ 5.41 | ||
| 10 | $ 3.62 | |||
| 25 | $ 3.16 | |||
| 100 | $ 2.64 | |||
| 250 | $ 2.39 | |||
| 500 | $ 2.23 | |||
| 1000 | $ 2.10 | |||
| Tape & Reel (TR) | 2500 | $ 1.80 | ||
| 5000 | $ 1.73 | |||
MAXM17626 Series
2.7V TO 5.5V
| Part | Applications | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Mounting Type | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Type | Control Features | Number of Outputs | Current - Output (Max) [Max] | Features | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Supplier Device Package [x] | Supplier Device Package | Supplier Device Package [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM17626AMB+ | ITE (Commercial) | 10-SMD Module | 125 °C | -40 °C | 0.1 in | 2.6 mm | 1.3 mm | 0.05 in | 0.08 " | 2.1 mm | Surface Mount | 0.8 V | 3.3 V | Non-Isolated PoL Module | Active Low, Enable | 1 | 600 mA | Adjustable Output | 5.5 V | 2.7 V | 2.6 | 10-eMGA | 2.1 |
Analog Devices Inc./Maxim Integrated MAXM17626AMB+T | ITE (Commercial) | 10-SMD Module | 125 °C | -40 °C | 0.1 in | 2.6 mm | 1.3 mm | 0.05 in | 0.08 " | 2.1 mm | Surface Mount | 0.8 V | 3.3 V | Non-Isolated PoL Module | Active Low, Enable | 1 | 600 mA | Adjustable Output, Remote On/Off | 5.5 V | 2.7 V | 2.6 | 10-eMGA | 2.1 |
Description
General part information
MAXM17626 Series
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.3V 600mA 2.7V - 5.5V Input
Documents
Technical documentation and resources
