GFE160032B-BNFBB01
ActiveGi Far technology Co., Ltd
160X32,STN-B,WHITE, 80X36MM(WITH
GFE160032B-BNFBB01
ActiveGi Far technology Co., Ltd
160X32,STN-B,WHITE, 80X36MM(WITH
Description
General part information
GFE160032B-BNFBB01
Graphic LCD Display Module Transflective STN - Super-Twisted Nematic Parallel
Technical Specifications
Parameters and characteristics for this part
| Specification | GFE160032B-BNFBB01 |
|---|---|
| Background Color | Yellow, Green |
| Backlight Color | Yellow, Green |
| Backlight Type | LED |
| Controller Type | NT7066U-F00 |
| Display Mode | Transflective |
| Display Type | STN - Super-Twisted Nematic |
| Dot Pitch Height | 0.55 mm |
| Dot Pitch Width | 0.45 mm |
| Dot Size Height | 0.5 mm |
| Dot Size Width | 0.41 mm |
| Interface | Parallel |
| Viewing Area Height | 13 mm |
| Viewing Area Width | 48 mm |
