Description
General part information
200LEX3.3MEFC6.3X11
3.3 µF 200 V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 125°C
Technical Specifications
Parameters and characteristics for this part
| Specification | 200LEX3.3MEFC6.3X11 |
|---|---|
| Applications | General Purpose |
| Capacitance | 3.3 µF |
| Height - Seated (Max) | 0.512 in |
| Lead Spacing | 0.098 in |
| Lifetime | 4000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Polarization | Polar |
| Ripple Current | 42 mA |
| Size / Dimension Diameter | 0.248 in |
| Tolerance | 20 % |
| Voltage - Rated | 200 VDC |
